12V CCTV Power Supply Box

  • 12V CCTV Power Box
  • 4 Port
  • 8 Port
  • 16 Port
  • 110V to 12V DC
  • Description

    12V Power Supply boxes are a must have for CCTV camera installations with 4 or more cameras. These boxes connect to a regular 110V power outlet and inside have a terminal board that outputs 12V DC voltage for multiple cameras. They come in a few varieties depending on the number of cameras, and the amount of amperage (aka current) they can support:

    • 4 Port 5 Amp
    • 9 Port 5 Amp
    • 9 Port 10 Amp
    • 18 Port 10 Amp
    • 18 Port 20 Amp

    Power distribution units such as these are not only preferred by installers, but also every day users installing their own security camera system. Please select the power box you would like to purchase from the selection list above.

    What’ Included?

    • (1) 12V DC Power Box
    • (1) Power Cable to connect box to 110V outlet

    If you’re wondering on how to use a power box along with analog security cameras and siamese cable from CCTV Camera World, please watch the video below.

    Here are specifications of each of the 12V Power Distribution Units you can choose above from this multi-product listing.

    12VDC 4 port 5 Amp Model (item 12045)

    Specifications

    • Input Voltage: 110V AC
    • Output Voltage: 12V DC Regulated
    • 12V DC Output 1.1 Amp per port
    • Total output current 5 Amp
    • 4 PTC Fuse protected outputs
    • Fuse Rating 1.1Amp
    • Power On/Off Switch
    • Power LED Indicator for each port or channel
    • Surge Protected



    12VDC 9 port 5 Amp Model (item 12095)

    Specifications

    • Input Voltage: 110V AC
    • Output Voltage: 12V DC Regulated
    • 12V DC Output 0.55 Amp per port
    • Total output current 5 Amp
    • 9 PTC Fuse protected outputs
    • Fuse Rating 1.1 Amp
    • Power On/Off Switch
    • Power LED Indicator for each port or channel
    • Surge Protected
    • Size: 9 3/4 x 8 x 3 3/4 inches (HxWxD)



    12VDC 9 port 10 Amp Model (item 120910) – High Powered

    Specifications

    • Input Voltage: 110V AC
    • Output Voltage: 12V DC Regulated
    • 12V DC Output 1.11 Amp per port
    • Total output current 10 Amp
    • 9 PTC Fuse protected outputs
    • Fuse Rating 2.0 Amp
    • Power On/Off Switch
    • Power LED Indicator for each port or channel
    • Surge Protected
    • Size: 9 3/4 x 8 x 3 3/4 inches (HxWxD)



    12VDC 18 port 10 Amp Model (item 121810)

    Specifications

    • Input Voltage: 110V AC
    • Output Voltage: 12V DC Regulated
    • 12V DC Output 0.55 Amp per port
    • Total output current 10 Amp
    • 18 PTC Fuse protected outputs
    • Fuse Rating 1.1 Amp
    • Power On/Off Switch
    • Power LED Indicator for each port or channel
    • Surge Protected
    • Size: 9 3/4 x 8 x 3 3/4 inches (HxWxD)



    12VDC 18 port 20 Amp Model (item 121820) – High Powered

    Specifications

    • Input Voltage: 110V AC
    • Output Voltage: 12V DC Regulated
    • 12V DC Output 1.11 Amp per port
    • Total output current 20 Amp
    • 18 PTC Fuse protected outputs
    • Fuse Rating 2.3 Amp
    • Power On/Off Switch
    • Power LED Indicator for each port or channel
    • Surge Protected
    • Size: 10.2 x 10.5 x 3 inches (HxWxD)
