4MP 2.7-12mm Lens CS Mount

  • 4 Megapixel Lens
  • 2.7-12mm
  • Varifocal Lens
  • Auto Iris
  • CS Mount
  • Description

    This 2.7-12mm varifocal lens is made of high quality optics making it suitable for use with high definition box cameras up to 4MP in resolution. The lens can be adjusted by hand to set the desired zoom length and focus.


    • High Quality 4MP Varifocal Lens
    • For use with Box Cameras
    • Compatible with cameras up to 4MP resolution
    • 1/2.7″ Auto Iris Lens F1.6
    • 2.7-12mm Manual Varifocal Lens
    • 102.6° to 29.9° Angle of View with a 1/2.7″ image sensor
    • DC Drive Iris Control
    • CS mount compatible
    • Lens zoom can be easily adjusted by hand

    What’s Included?

    • (1) 4MP Varifocal camera lens


    Image format 1/2.7″
    Focal length 2.7-12mm
    Lens pixel 4MP
    Aperture F1.6
    Field Angle(D*H*V) 1/2.7” W: 137.8°(D)x102.6°(H)x74.3°(V)~T: 37.2°(D)x29.9°(H)x22.6°(V)
    1/3″ W: 120.1°(D)x91.3°(H)x66.3°(V)~T: 33.9°(D)x27.1°(H)x20.3°(V)
    Minimum Object Distance 11.8″ (0.3m)
    IR Correction Yes
    Lens Control Focus Manual
    Zoom Manual
    Iris DC-Iris
    Mount CS
    Dimension 33.7mm diameter x 57.6mm length
    Weight 3 oz
    Operating temperature -22°F to 140°F
    Humidity Less than 90% RH
